1.Function and Feature
Double frequency simple machanical structure, easy maintenance, less vibration and lower noise, less wear and tear, with long longevity. Double film supporting structure, easy for changing the film supporting structure, easy for changing the film. Big touching screen with human-machine surface, easier for operation. Double frequency with stepless adjustment speed, packing speed and the length can be adjusted casually. High-precision fiber magic eye makes the correct tracking, correct sealing and cutting position; sealing temperature is independently controlled. It is equipped with code printer, the printing position can be set casually.
This machine is with CE certificate.
2.Main Technical Parameter
Center Distance: 192mm
Packing Speed: 35-120 bags/min
Max Film Width: 450mm
Finished Bag Size:(150-250)x140mm(LxWxH)(Max)
Max Height: 120mm
Motor Power: 0.75 , 0.2 KW
Weight: 900 kg
Machine Noise: <=78db
Pass Percent of Finished Bag ( Percentage): >=97%
Sealing pressure: 15 newton/mm
Outsize Dimension of Machine: 4432x1115x1750mm(LxWxH)(with tool stock)
Type Of Power Supply: 380V 50HZ
Packing Film: OPP, PE, PVC, OPP/CPP, PT/PE |
